New system in Aliplast offer - FR90 SLIDE

Thermally insulated automatic fire-rated door system structures based on the FR90 SLIDE system provide the EI30 fire resistance class according to PN-EN 13501-2 of 2016.

 FR90 slide

Characteristic of construction:

  • chambers of the profiles are filled with fireproof inserts
  • universality and unification of profiles with the FR90 system
  • esthetic labyrinth connection of the sashes
  • symmetrically glazing
  • maximum dimensions of the structure 4900 mm x 3500 mm
  • maximum dimensions of the leaf glass pane: 1193,5 x 2339 mm
  • maximum dimensions of sash: 1369 x 2472 mm (joggle connection)
  • dedicated automation solution: Dorma
  • structures: double door, sliding externally, side and top lites
  • a wide range of colours – RAL palette (Qualicoat 1518), structural colours, Aliplast Wood Colour Effect (Qualideco PL-0001), anodic (Qualanod 1808)  and bi-colour
LEAFLET FR90 SLIDE
