a system with thermal insulation used to design sliding doors; the system is characterised by no glazing strips
infills are installed at the leaf installation stage in leaf C-shaped rabbets without glazing strips, with a seal which surrounds the infill
the frames are available in two versions: with an extruded slide rail and a separate profile for travelling trolleys
(mounted at the lower sections of the leaves); vertical leaf profiles have a profiled grip along the entire leaf height
the grips also provide static reinforcement of the structure
leaf corners are joined by screwing, whereas the frames can be screwed or crimped
there is possibility of use Flyscreen system (Flyscreen – fly screens are a practical andan extremely functional protection against insects)
a wide range of colours – RAL palette (Qualicoat 1518), texture colours, Aliplast Wood Colour Effect (wood-like colours), Aliplast Loft View – colours imitating stone surfaces (Qualideco PL-0001), anodised colour (Qualanod 1808), bi-colour

Show

RAL

Wood Colour

Bicolor

Anode

TECHNICAL SPECIFICATION

SYSTEM	MATERIAL	DEPTH OF FRAME	DEPTH OF LEAF	GLAZING RANGE	WEIGHT OF LEAF	TYPE OF DOORS
SL+	aluminium/polyamide	59-103 mm	32 mm	6 - 9 mm / 20-24 mm	to 120 kg	sliding

PERFORMANCE

SYSTEM	THERMAL INSULATION UF*	AIR PERMEABILITY	WINDLOAD RESISTANCE	WATERTIGHTNESS
SL+	Uf from 3,63 W/m2K	Class 3; EN 12207	Class B3 (1200 Pa); EN 12210	Class 5A (200 Pa); EN 12208
